| Camera General Information | |
|---|---|
| Image Sensor | CMOS Progressive 1/2.8”, Sony IMX675 |
| Resolution | 2592 x 1944 |
| Lens | Fixed lens, 2.8mm, F1.6 |
| Field of View | H: 96.9°, V: 73.1°, D: 122.9° |
| Day / Night | True Day / Night |
| Smart IR | Effective distance is up to 30M |
| WDR | Up to 120 dB depending on scene |
| Minimum Illumination | Color 0.15 lux |
| Image Enhance | Brightness, Contrast, Saturation, Sharpness, Mirror, Flip, Corridor, Anti-flicker, BLC, AWB |
| Defog | Support |
| Analytics (In-house VA) | Line Crossing, Object-Counting, Zone Object-Counting, Zone Intrusion, Loitering, Wrong Way, Left, Remove |
| Video and Audio | |
| Video Compression | H.265 / H.264 / M-JPEG |
| Smart Compression | Smart GOP |
| Video Resolution | 2592 x 1944 to 640x480 |
| Video Quality | CBR, VBR, MJPEG |
| Frame Rate (Max Resolution) | Up to 30fps |
| Frame Rate (Multi-Stream) | Up to 30fps 2592x1944 (H.265/H.264) + 30fps 1280x720 (H.265/H.264) + 15fps 640x480 (MJPEG) |
| Audio Streaming | Two-way audio supported |
| Audio Compression | G.711 (A-Law/U-Law) |
| Network | |
| Interface | 10/100 Mbps Ethernet, RJ45 |
| Browser | Edge, Chrome, Firefox, Safari |
| ONVIF | ONVIF S, G, T, M |
| Event Management | |
| Event Trigger | Motion detection, Tampering Alarm, Alarm In |
| Notifications | Send message via e-mail / Record to FTP/NAS/SD card, record JPG/mp4 |
| General | |
| Power | PoE IEEE 802.3af, Class 3 |
| Power Consumption | PoE: 5.11W DC12V: 5.4W |
| Audio In/Out Port | Line-in x 1 ; Line-out x 1 |
| DI/DO | DI x 1; DO x 1 |
| Storage | MicroSD/SDHC/SDXC, up to 1.5TB *1 |
| Operating Temperature | –40°C (-40°F) to 40°C (104°F) (IR on) –40°C (-40°F) to 50°C (131°F) (IR off) |
| Storage Temperature | –40°C (-40°F) to 60°C (140°F) |
| Humidity | 10–90% RH (non-condensing) (from 50°C drop to -10°C within 3 hours) |
| Regulation | CE/FCC/UL/UKCA |
| Waterproof | IP67 |
| Vandal Resistant | IK10 |
| Application | SDK available for application development |
| Packaging Information | |
| Weight | 850g |
| Dimension | Ø150mm x H 65mm |
